SPECIFICATIONS

Applications: Outdoor

Battery Capacity: Without Battery

Modulation Type: CW, LSB, USB, AM, NFM, WFM, DIGI

Operating Voltage: DC13.8V±15%

Output Power: Max 100W

Private Mold: Yes

Product Name: HF SDR Transceiver

Radio Type: Ham Radio

Warranty: 12 Months

Weight: 4020g

brand name: Recent

frequency range: RX: 0.5~750MHz; TX: 0.5~30MHz

frequency type: HF & VHF

model number: RS-998

operating language: English

output power: 100W

place of origin: Fujian, China

storage channel: More than 1000

talk range: >900km

walkie talkie type: HF SDR

water resistance level: IPX5

Features

7" multi-point capacitive touch screen, 3D waterfall spectrum diagram
Dynamic display of dashboard interface
A+B or A&B dual channel hybrid stereo
Bandwidth adjustable: 0Hz - 2700Hz for HPF and 100Hz - 20kHz for LPF
Built-in KSV/ power meter (KV)
Automatic and manual notch filters
Frequency band chart for automatic mode switching
Digital Noise Reduction (DNR), Pulse noise reduction (NB)
CAT virtual COM port (simulating FT-450 and TS-2000), CW port
Spectrum analysis, SWR antenna standing-wave analysis
SSB/FM Scanning mode
Digital Recording
WiFi networking operation
Firmware upgrade through USB, SD and WiFi
Built-in WIFI！Online radio is displayed after networking
Built-in CW decode, FT8 encode and decode (No additional device required)
Built-in TF card！Multiple recordings and playback! Recording call, CW mode with 5 recordings
TF card flash upgrade！
Multi scene mode selection! Fully open source software and hardware can be modified as per needed
Built-in USB sound card for easy connection
All aluminum anodizing housing! Precision design and production!
Built-in antenna tuner
Low Noise Amplifier LNA
Band-pass Filter

Specification

Frequency Range:			RX: 0.5～750MHz TX: 0.5～30MHz (TX on amateur band only); 144～148MHz
Operating Voltage:			DC13.8V±15%
Display Screen:			7" color LCD display screen
Antenna Impedance:			50Ω, SL16 socket, two antenna input options
TX Power:			≤100W (HF), ≤60W (VHF)
Receiving Sensitivity:			-110dBm @12dB SNAD
Main Reference Frequency:			122.88MHz
Modulation Type:			CW, LSB, USB, AM, NFM, WFM, DIGI
Number of Memory Channels:			36
Adjustable Attenuator:			0～31dB
TX Current:			≤20A
Current:			≤1.5A (Speaker ON)
Operating Temperature:			－20℃～＋60℃
Storage Temperature:			－40℃～＋85℃
Dimensions (W×H×D):			340mm×155mm×211mm
Weight (Hand MIC Included)			4020
