8 Band USDX USDR HF QRP SDR Transceiver SSB/CW Transceiver Built-in Battery QRP CW Transceiver with Mic Shortwave Transceiver Charger
Feature:
1. Exquisite Design: The USDX QRP SSB/CW transceiver features an exquisite alumina casing that not only lends it a premium appearance but also offers enhanced safety and durability for long-term use.
2. Built-in Mic for Handheld Use: Equipped with an in-built mic, this HF ham radio is designed for handheld use, providing convenience and flexibility during communication or exploration activities.
3. IRF Series Transmitting Tube: Our QRP CW transceiver uses IRF series transmitting tubes known for their longevity and efficiency. Rest assured knowing your transceiver is equipped with industry-leading technology.
4. Large Battery Capacity: With a large battery of 6000mAh, our shortwave transceiver ensures long hours of usage. It also features power and SWR indicators to help monitor the device's performance and signal strength.
5. Adjustable CW Sidetone Volume: The shortwave transceiver allows for adjustments in the CW sidetone volume, ensuring optimal audibility based on your preference. With its simple circuitry, the transceiver is easy to operate, making it a user-friendly choice for all.



Specification:
The USDR/USDX Is A Pocket 8-Band SSB/CW QRP Transceiver With A Built-In Lithium Battery, Built-In Microphone, Ptt Button And Extremely Low Rx Current Consumption. It Is A Great Companion For Sota, Pota Or Any Other Portable Activity.
This QRP SSB/CW Shortwave Transceiver Has 1602 Screen, Built-In Battery, Equipped With Charger, Built-In Microphone, Speaker, Can Be Connected To Automatic Buttons, Also Can Cw Decoding.
Product Features:
1. Adopt IRF Series Transmitting Tube, .
2. Can Be Used To Connect The Antenna (Instrument Base).
3. Aluminum Housing Marking, All Aluminum Button, Translucent Silicone Button.
4. The Original Qcx Circuit Is Greatly Simplified, And The Installed Components Are Reduced By 50%. No Complex Transformer Windings, No Wiring Procedures, Most Cost Effective And Easy To Construct.
Band 5.8. Radio Wave Digital Display! Max External Power Supply 13.8v 10w! Built-In 12.6v Battery

Port Description:
Charging: Built-In Lithium Battery Charging Port, Only Use The Included Charger! No Other Chargers!
Bat: Internal Battery Power Supply. 13.8: External Power Supply
Dc13.8v/3a: External Power Port
Key: Automatic Body Connection (A, B, Single Key)
Pa: External Power Amplifier, Ptt Signal
Mic: External Microphone Interface
Uart: Serial Communication (Ts-480 Compatible Instruction)
Spk: External Speaker
Product Size: 130.00 X 70.00 X 60.00 MM/5.12 X 2.76 X 2.36 Inch
Product Type: Adapter
Material: Metal
Is It Packaged? Yes

Note:
Due To The Different Monitor And Light Effect, The Actual Color Of The Item Might Be Slightly Different From The Color Showed On The Pictures. Thank You!
Please Allow 1-2 CM Measuring Deviation Due To Manual Measurement.

1 X SSB/CW Transceiver
1 X Handheld Microphone
1 X Charging Cable (EU Plug)
